AM3359, AM3358, AM3357
AM3356, AM3354, AM3352
SPRS717F –OCTOBER 2011–REVISED APRIL 2013
www.ti.com
TI device nomenclature also includes a suffix with the device family name. This suffix indicates the
package type (for example, ZCE), the temperature range (for example, blank is the default commercial
temperature range), and the device speed range, in megahertz (for example, 27 is 275 MHz). Figure 6-1
provides a legend for reading the complete device name for any AM335x device.
For orderable part numbers of AM335x devices in the ZCE and ZCZ package types, see the Package
Option Addendum of this document, the TI website (www.ti.com), or contact your TI sales representative.
For additional description of the device nomenclature markings on the die, see the AM335x ARM Cortex-
A8 Microprocessors (MPUs) Silicon Errata (literature number SPRZ360).
(
)
X
(
)
AM3358
B
ZCZ
PREFIX
DEVICE SPEED RANGE
27 = 275-MHz Cortex-A8
30 = 300-MHz Cortex-A8
50 = 500-MHz Cortex-A8
60 = 600-MHz Cortex-A8
72 = 720-MHz Cortex-A8
80 = 800-MHz Cortex-A8
100 = 1-GHz Cortex-A8
X = Experimental device
Blank = Qualified device
DEVICE(A)
ARM Cortex-A8 MPU:
AM3352
AM3354
AM3356
AM3357
AM3358
AM3359
TEMPERATURE RANGE
Blank = 0°C to 90°C (commercial junction temperature)
A = -40°C to 105°C (extended junction temperature)
D = -40°C to 90°C (industrial junction temperature)
DEVICE REVISION CODE
Blank = silicon revision 1.0
A = silicon revision 2.0
PACKAGE TYPE(B)
ZCE = 298-pin plastic BGA, with Pb-Free solder balls
ZCZ = 324-pin plastic BGA, with Pb-Free solder balls
B = silicon revision 2.1
A. The AM3358 device shown in this device nomenclature example is one of several valid part numbers for the AM335x
family of devices. For orderable device part numbers, see the Package Option Addendum of this document.
B. BGA = Ball Grid Array.
Figure 6-1. AM335x Device Nomenclature
6.2 Documentation Support
6.2.1 Related Documentation from Texas Instruments
The following documents describe the AM335x MPU. Copies of these documents are available on the
Internet at www.ti.com. Tip: Enter the literature number in the search box.
The current documentation that describes the AM335x MPU, related peripherals, and other technical
collateral, is available in the product folder at: www.ti.com.
SPRUH73 AM335x ARM Cortex-A8 Microprocessors (MPUs) Technical Reference Manual.
Collection of documents providing detailed information on the AM335x device including
power, reset, and clock control, interrupts, memory map, and switch fabric interconnect.
Detailed information on the microprocessor unit (MPU) subsystem as well as a functional
description of the peripherals supported on AM335x devices is also included.
SPRZ360
AM335x ARM Cortex-A8 Microprocessors (MPUs) Silicon Errata. Describes the known
exceptions to the functional specifications for the AM335x ARM Cortex-A8 Microprocessors.
6.2.2 Community Resources
The following links connect to TI community resources. Linked contents are provided "AS IS" by the
respective contributors. They do not constitute TI specifications and do not necessarily reflect TI's views;
see TI's Terms of Use.
TI E2E Community TI's Engineer-to-Engineer (E2E) Community. Created to foster collaboration
among engineers. At e2e.ti.com, you can ask questions, share knowledge, explore ideas and
help solve problems with fellow engineers.
TI Embedded Processors Wiki Texas Instruments Embedded Processors Wiki. Established to help
226
Device and Documentation Support
Copyright © 2011–2013, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
