ALM2403-Q1
ZHCSMT3A –NOVEMBER 2020 –REVISED MARCH 2023
www.ti.com.cn
To
For optimal thermal performance,
connect exposed pad to as much
top-layer copper as possible, as well
as vias to underlying ground layers.
Supply
Voltage
Connect a ceramic
bypass capacitor from
V+ at pin 12 to GND
through vias and metal
on an internal layer.
Input 1
V–
IN1–
IN1+
Output, Channel 1
OUT1
OTF/SH_DN
IN2+
V+
To
Supply
V+
Voltage
Input 2
V+
IN2–
OUT2
V–
Output, Channel 2
NC
NC
Connect a ceramic
bypass capacitor from
V+ at pin 10 to GND
through vias and metal
on an internal layer.
To
Supply
Voltage
图8-6. ALM2403-Q1 Layout Example
