ADS7056
www.ti.com.cn
ZHCSG66 –MARCH 2017
EXAMPLE BOARD LAYOUT
RUG0008A
X2QFN - 0.4 mm max height
PLASTIC QUAD FLATPACK - NO LEAD
2X (0.3)
2X (0.6)
8
6X (0.55)
1
7
4X (0.25)
SYMM
(1.3)
4X (0.5)
2X (0.2)
3
5
(R0.05) TYP
4
SYMM
(1.35)
LAND PATTERN EXAMPLE
SCALE:25X
0.07 MAX
ALL AROUND
0.07 MIN
ALL AROUND
SOLDER MASK
OPENING
METAL
SOLDER MASK
OPENING
METAL
UNDER
SOLDER MASK
NON SOLDER MASK
DEFINED
(PREFERRED)
SOLDER MASK
DEFINED
SOLDER MASK DETAILS
NOT TO SCALE
4222060/A 05/14/2015
NOTES: (continued)
3. For more information, see Texas Instruments literature number SLUA271 (www.ti.com/lit/slua271).
