PACKAGE OUTLINE
PW0020A
TSSOP - 1.2 mm max height
S
C
A
L
E
2
.
5
0
0
SMALL OUTLINE PACKAGE
SEATING
PLANE
C
6.6
6.2
TYP
A
0.1 C
PIN 1 INDEX AREA
18X 0.65
20
1
2X
5.85
6.6
6.4
NOTE 3
10
B
11
0.30
20X
4.5
4.3
NOTE 4
0.19
1.2 MAX
0.1
C A B
(0.15) TYP
SEE DETAIL A
0.25
GAGE PLANE
0.15
0.05
0.75
0.50
A
20
0 -8
DETAIL A
TYPICAL
4220206/A 02/2017
NOTES:
1. All linear dimensions are in millimeters. Any dimensions in parenthesis are for reference only. Dimensioning and tolerancing
per ASME Y14.5M.
2. This drawing is subject to change without notice.
3. This dimension does not include mold flash, protrusions, or gate burrs. Mold flash, protrusions, or gate burrs shall not
exceed 0.15 mm per side.
4. This dimension does not include interlead flash. Interlead flash shall not exceed 0.25 mm per side.
5. Reference JEDEC registration MO-153.
