SFF1601GA thru SFF1608GA
Pb
SFF1601GA thru SFF1608GA
Pb Free Plating Product
16.0 Amperes Insulated Common Anode Super Fast Recovery Rectifiers
Unit : inch (mm)
ITO-220AB/TO-220F-3L
Features
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
Super fast switching for high efficiency
.189(4.8)
.165(4.2)
.406(10.3)
.381(9.7)
.134(3.4)
.118(3.0)
Low forward voltage drop
High current capability
Low reverse leakage current
High surge current capability
.130(3.3)
.114(2.9)
Application
Automotive Inverters and Solar Inverters
ꢀ
ꢀ
ꢀ
Plating Power Supply,SMPS and UPS
.114(2.9)
.098(2.5)
.071(1.8)
.055(1.4)
Car Audio Amplifiers and Sound Device Systems
.055(1.4)
.039(1.0)
.035(0.9)
.011(0.3)
.032(.8)
MAX
Mechanical Data
.1
(2.55)
.1
ꢀ
ꢀ
ꢀ
Case: ITO-220AB full plastic isolated package
Epoxy: UL 94V-0 rate flame retardant
Terminals: Solderable per MIL-STD-202
method 208
(2.55)
Case
Case
Case
Case
ꢀ
ꢀ
ꢀ
Polarity: As marked on diode body
Mounting position: Any
Weight: 1.75 gram approximately
Doubler
Series
Negative
Common Cathode Common Anode
Suffix "G" Suffix "GA"
Positive
Tandem Polarity Tandem Polarity
Suffix "GD"
Suffix "GS"
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS (TA=25℃ unless otherwise noted)
SFF
SFF
SFF
SFF
SFF
SFF
SFF
SFF
PARAMETER
SYMBOL
UNIT
1601GA 1602GA 1603GA 1604GA 1605GA 1606GA 1607GA 1608GA
Maximum repetitive peak reverse voltage
Maximum RMS voltage
VRRM
VRMS
VDC
50
35
50
100
70
150
105
150
200
140
200
300
210
300
400
280
400
500
350
500
600
420
600
V
V
V
A
Maximum DC blocking voltage
100
Maximum average forward rectified current
IF(AV)
16
Peak forward surge current, 8.3 ms single half
sine-wave superimposed on rated load
IFSM
125
A
V
Maximum instantaneous forward voltage (Note 1)
IF = 8 A
VF
0.975
1.3
1.7
10
400
35
Maximum reverse current @ Rated VR TJ=25 ℃
TJ=125 ℃
IR
μA
Maximum reverse recovery time (Note 2)
Typical junction capacitance (Note 3)
Typical thermal resistance
Trr
Cj
ns
pF
80
50
RθJC
TJ
3.0
°C/W
°C
Operating junction temperature range
Storage temperature range
- 55 to +150
- 55 to +150
TSTG
°C
Note 1: Pulse Test with PW=300μs, 1% Duty Cycle
Note 2: Reverse Recovery Test Conditions: IF=0.5A, IR=1.0A, IRR=0.25A.
Note 3: Measured at 1 MHz and Applied Reverse Voltage of 4.0V D.C.
Page 1/2
