 浏览型号FMXS-2206S的Datasheet PDF文件第2页
FMXS-2206S
FMXS-2206S
Pb Free Plating Product
20Amperes,600Volts Insulated Common Cathode Ultra Fast Recovery Rectifiers
Unit : inch (mm)
ITO-220AB/TO-220F-3L
APPLICATION
.189(4.8)
.406(10.3)
.165(4.2)
.381(9.7)
· Freewheeling, Snubber, Clamp
· Inversion Welder
· PFC
.134(3.4)
.130(3.3)
.114(2.9)
.118(3.0)
· Plating Power Supply
· Ultrasonic Cleaner and Welder
· Converter & Chopper
· UPS
.114(2.9)
.098(2.5)
.071(1.8)
.055(1.4)
.055(1.4)
.039(1.0)
.035(0.9)
.011(0.3)
.032(.8)
MAX
PRODUCT FEATURE
· Ultrafast Recovery Time
.1
(2.55)
.1
(2.55)
· Soft Recovery Characteristics
· Low Recovery Loss
Case
Case
Case
Case
· Low Forward Voltage
Doubler
Tandem Polarity Tandem Polarity
Suffix "U" Suffix "UR"
Series
Negative
Common Cathode Common Anode
Suffix "S" Suffix "R"
Positive
· High Surge Current Capability
· Low Leakage Current
GENERAL DESCRIPTION
FMXS-2206S using the lastest FRED FAB process(planar passivation chip) with ultrafast and soft recovery characteristic.
Absolute Maximum Ratings
Parameter
Symbol
Test Conditions
Values
Units
Repetitive peak reverse voltage
VRRM
600
V
(total device)
Continuous forward current
IF(AV)
20
Tc =110°C
A
(total device)
Single pulse forward current
IFSM
IFRM
Tj
160
60
Tc =25°C
Maximum repetitive forward current
Operating junction
Square wave, 20kHZ
175
°C
°C
Storage temperatures
Tstg
-55 to +175
Rev.08T
© 1995 Thinki Semiconductor Co., Ltd.
Page 1/2
