 浏览型号FFA60UP30DN的Datasheet PDF文件第2页
FFA60UP30DN
FFA60UP30DN
Pb Free Plating Product
60Amperes,300Volts Dual Common Cathode Ultra Fast Recovery Rectifiers
TO-3PB(TO-3PN)
APPLICATION
Cathode(Bottom Side Metal Heatsink)
· Freewheeling, Snubber, Clamp
· Inversion Welder
· PFC
· Plating Power Supply
· Ultrasonic Cleaner and Welder
· Converter & Chopper
· UPS
Anode
PRODUCT FEATURE
Cathode
· Ultrafast Recovery Time
Internal Configuration
Anode
· Soft Recovery Characteristics
· Low Recovery Loss
Base Backside
· Low Forward Voltage
· High Surge Current Capability
· Low Leakage Current
GENERAL DESCRIPTION
FFA60UP30DN using the lastest FRED FAB process(planar passivation chip) with ultrafast and soft recovery characteristic.
Absolute Maximum Ratings
Parameter
Symbol
Test Conditions
Values
Units
Repetitive peak reverse voltage
VRRM
300
V
Continuous forward current
IF(AV)
60
Tc =110°C
A
Single pulse forward current
Maximum repetitive forward current
Operating junction
IFSM
IFRM
Tj
600
150
175
Tc =25°C
Square wave, 20kHZ
°C
°C
Storage temperatures
Tstg
-55 to +175
Electrical characteristics (Ta=25°C unless otherwise specified)
Parameter
Symbol
VBR,
Test Conditions
Min
Typ.
Max.
Units
Breakdown voltage
Blocking voltage
IR=100µA
300
VR
IF=30A
0.96
0.85
1.20
1.00
10
V
Forward voltage
(Per Diode)
VF
IF=30A, Tj =125°C
VR= VRRM
Reverse leakage
IR
µA
current(Per Diode)
100
Tj=150°C, VR=300V
IF=0.5A, IR=1A, IRR=0.25A
35
26
45
40
Reverse recovery
time(Per Diode)
trr
ns
IF=1A,VR=30V, di/dt =200A/us
Thermal characteristics
Paramter
Symbol
Typ
0.8
Units
/W
Junction-to-Case
RθJC
Rev.08T
© 1995 Thinki Semiconductor Co., Ltd.
Page 1/2
