(27/34)
MULTILAYER CERAMIC CHIP CAPACITORS
Temperature characteristic: JB (–25 to +85°C, ±10ꢃꢁ
Capacitance range table
Catalog number
Thickness
（mm）
Capacitance
Capacitance Dimensions
3216
tolerance
10%
20%
10%
20%
10%
20%
10%
20%
10%
20%
10%
20%
10%
20%
10%
20%
10%
20%
10%
20%
10%
20%
10%
20%
Rated voltage Edc: 250V
Rated voltage Edc: 100V
C3216JB2A105K160AA
C3216JB2A105M160AA
C3225JB2A105K200AA
C3225JB2A105M200AA
C4532JB2A105K230KA
C4532JB2A105M230KA
C5750JB2A105K230KA
C5750JB2A105M230KA
C3225JB2A155K200AB
C3225JB2A155M200AB
C4532JB2A155K230KA
C4532JB2A155M230KA
C5750JB2A155K230KA
C5750JB2A155M230KA
C3225JB2A225K230AB
C3225JB2A225M230AB
C4532JB2A225K230KA
C4532JB2A225M230KA
C5750JB2A225K230KA
C5750JB2A225M230KA
C5750JB2A335K230KA
C5750JB2A335M230KA
C5750JB2A475K230KA
C5750JB2A475M230KA
1.60 0.20
2.00 0.20
2.30 0.20
2.30 0.20
2.00 0.20
2.30 0.20
2.30 0.20
2.30 0.20
2.30 0.20
2.30 0.20
2.30 0.20
2.30 0.20
3225
1µF
4532
C5750JB2E105K230KA
C5750JB2E105M230KA
5750
3225
1.5µF
2.2µF
4532
5750
3225
4532
5750
5750
5750
3.3µF
4.7µF
■ Gray items: These products are not recommended for new designs.
Click the part numbers for details.
Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.
Please note that the contents may change without any prior notice due to reasons such as upgrading.
