Capacitance
Range Table
C3225 [EIA CC1210]
Class 1 (Temperature Compensating)
Temperature Characteristics: C0G (-55 to 125ºC, 0±30 ppm/ºC)
TDK Part Number
(Ordering Code)
Temperature
Characteristics
Rated
Voltage
Capacitance
(pF)
Capacitance
Tolerance
Thickness
(mm)
C3225C0G1H223J
C3225C0G1H333J
C3225C0G1H473J
C3225C0G1H683J
C3225C0G1H104J
C0G
C0G
C0G
C0G
C0G
50V
50V
50V
50V
50V
22,000
± 5%
± 5%
± 5%
± 5%
± 5%
1.30 ± 0.15
1.60 ± 0.30
2.00 ± 0.20
2.00 ± 0.20
2.50 ± 0.30
33,000
47,000
68,000
100,000
Class 2 (Temperature Stable)
Temperature Characteristics: X7R (-55 to +125ºC, ±15%), X7S (-55 to +125ºC, ±22%), X6S (-55 to +105ºC, ±22%)
TDK Part Number
(Ordering Code)
Temperature
Characteristics
Rated
Voltage
Capacitance
(pF)
Capacitance
Tolerance
Thickness
(mm)
C3225X7R1H474K/1.30
C3225X7R1H474M/1.30
C3225X7R1H105K/1.60
C3225X7R1H105M/1.60
C3225X7R1H105K/2.00
C3225X7R1H105M/2.00
C3225X7R1H155K
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X6S
X6S
X7S
X7S
X7S
X7S
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
X7R
50V
50V
50V
50V
50V
50V
50V
50V
50V
50V
50V
50V
50V
50V
50V
50V
50V
50V
50V
50V
50V
50V
25V
25V
25V
25V
25V
25V
25V
25V
25V
25V
16V
16V
16V
470,000
± 10%
± 20%
± 10%
± 20%
± 10%
± 20%
± 10%
± 20%
± 10%
± 20%
± 10%
± 20%
± 10%
± 20%
± 10%
± 20%
± 10%
± 20%
± 10%
± 20%
± 10%
± 20%
± 10%
± 20%
± 10%
± 20%
± 10%
± 20%
± 10%
± 20%
± 10%
± 20%
± 10%
± 20%
± 20%
1.30 ± 0.15
1.30 ± 0.15
1.60 ± 0.30
1.60 ± 0.30
2.00 ± 0.20
2.00 ± 0.20
2.00 ± 0.20
2.00 ± 0.20
2.00 ± 0.20
2.00 ± 0.20
2.50 ± 0.30
2.50 ± 0.30
2.50 ± 0.30
2.50 ± 0.30
2.50 ± 0.30
2.50 ± 0.30
2.50 ± 0.30
2.50 ± 0.30
2.50 ± 0.30
2.50 ± 0.30
2.50 ± 0.30
2.50 ± 0.30
1.60 ± 0.30
1.60 ± 0.30
1.60 ± 0.30
1.60 ± 0.30
2.00 ± 0.20
2.00 ± 0.20
2.50 ± 0.30
2.50 ± 0.30
2.50 ± 0.30
2.50 ± 0.30
2.00 ± 0.20
2.00 ± 0.20
2.50 ± 0.30
470,000
1,000,000
1,000,000
1,000,000
1,000,000
1,500,000
1,500,000
2,200,000
2,200,000
2,200,000
2,200,000
3,300,000
3,300,000
4,700,000
4,700,000
4,700,000
4,700,000
6,800,000
6,800,000
10,000,000
10,000,000
2,200,000
2,200,000
3,300,000
3,300,000
4,700,000
4,700,000
6,800,000
6,800,000
10,000,000
10,000,000
10,000,000
10,000,000
15,000,000
C3225X7R1H155M
C3225X7R1H225K/2.00
C3225X7R1H225M/2.00
C3225X7R1H225K/2.50
C3225X7R1H225M/2.50
C3225X7R1H335K
C3225X7R1H335M
C3225X7R1H475K
C3225X7R1H475M
C3225X6S1H475K
C3225X6S1H475M
C3225X7S1H685K
C3225X7S1H685M
C3225X7S1H106K
C3225X7S1H106M
C3225X7R1E225K/1.60
C3225X7R1E225M/1.60
C3225X7R1E335K
C3225X7R1E335M
C3225X7R1E475K
C3225X7R1E475M
C3225X7R1E685K/2.50
C3225X7R1E685M/2.50
C3225X7R1E106K
C3225X7R1E106M
C3225X7R1C106K
C3225X7R1C106M
C3225X7R1C156M
TDK MLCC US Catalog
Page 56
Version B11
