CAPACITANCE RANGES: CLASS 2
TEMPERATURE CHARACTERISTICS: X7S( 22ꢁ)
Part No.
Dimension Thickness
Capacitance
tolerance
Capacitance
L×W
T(mm)
Rated voltage Edc: 50V
C3225X7S1H685K(250AB)
C3225X7S1H685M(250AB)
C3225X7S1H106K(250AB)
C3225X7S1H106M(250AB)
Rated voltage Edc: 35V
Rated voltage Edc: 25V
Rated voltage Edc: 16V
10%
20%
10%
20%
6.8µF
3225
2.50 0.20
10µF
3225
2.50 0.20
TEMPERATURE CHARACTERISTICS: X7S( 22ꢁ)
Part No.
Dimension Thickness
Capacitance
tolerance
Capacitance
100nF
220nF
470nF
1µF
L×W
T(mm)
Rated voltage Edc: 10V
Rated voltage Edc: 6.3V
Rated voltage Edc: 4V
10%
20%
10%
20%
10%
20%
10%
20%
10%
20%
10%
20%
10%
20%
20%
C0603X7S0G104K(030BC)
C0603X7S0G104M(030BC)
C0603X7S0G224K(030BC)
C0603X7S0G224M(030BC)
0603
0.30 0.03
0603
1005
1005
1608
1608
0.30 0.03
0.50 0.05
0.50 0.05
0.80 0.10
0.80 0.10
C1005X7S1A474K(050BC) C1005X7S0J474K(050BB)
C1005X7S1A474M(050BC) C1005X7S0J474M(050BB)
C1005X7S0G105K(050BC)
C1005X7S0G105M(050BC)
C1608X7S1A225K(080AC) C1608X7S0J225K(080AB)
C1608X7S1A225M(080AC) C1608X7S0J225M(080AB)
2.2µF
C1608X7S0G475K(080AC)
C1608X7S0G475M(080AC)
C2012X7S0G106K(085AC)
C2012X7S0G106M(085AC)
4.7µF
10µF
47µF
2012
3225
0.85 0.10
2.50 0.30
C3225X7S0J476M(250AC)
