1. Introduction
This miniaturized low profile PCB antenna is based on smart TheStripe™ antenna
technology. It consists of a PCB antenna and 1.13mm co-axial cable with IPEX MHFI
(U.FL) connector.
2. Specification
ELECTRICAL
Frequency (MHz)
Free Space Peak Gain
Free Space Efficiency
Impedance
824 ~ 896
-4.1dBi
13%
880~960
-13dBi
8%
1710~1880
0.6dBi
1850~1990
-0.4dBi
11%
51%
50Ω
Polarization
Linear
Omni
Radiation Pattern
MECHANICAL
Antenna Dimensions
Cable
34 x 7 x 0.8mm
1.13 co-axial
IPEX MHF I
Connector
ENVIRONMENTAL
Operation Temperature
Humidity
-40°C to 85°C
Non-condensing 65°C 95% RH
SPE-11-8-124/C
Page 2 of 11
