MECHANICAL
Antenna Dimensions
Height 85.7mm x Diameter 145.6mm
Casing
Waterproof
Wonderloy PC-540 PC/ABS Alloy
IP67
2G/3G/4G MIMO 1
2G/3G/4G MIMO 2
2.4/5GHz MIMO 1
2.4/5GHz MIMO 2
GPS/GLONASS/GALILEO
Base and thread
Thread diameter
Nut
3M CFD-200 SMA(M)
3M CFD-200 SMA(M)
3M CFD-200 RP-SMA(M)
3M CFD-200 RP-SMA(M)
3M RG-174 SMA(M)
CAN10 Zinc Alloy
M30 x 2 (30mm)
Nickel Plated Steel
3M 9448HK
Foam
Waterproof
IP67
1.29(antenna)
1.53(with box)
Weight(kg)
Recommended Torque for
Mounting
49 N∙m
Max Torque for Mounting
58.8N∙m
ENVIRONMENTAL
Operation Temperature
Storage Temperature
Humidity
-40°C to 85°C
-40°C to 90°C
Non-condensing 65°C 95% RH
* all measurements were conducted with 3m low loss CFD200 cable
SPE-12-8-150/G/PK
Page 4 of 25
MA750.W.A301111.B305111.I305111.C305151.G305151 White
