SM5958
8-Bit Micro-controller
32KB with ISP Flash
& 1KB RAM embedded
Product List
SM5958W40PP,
SM5958W44JP,
SM5958W44QP,
Features
Main Flash ROM 32KB.
Working voltage 2.4V~5.5V.
4.5V ~ 5.5V runs up to 40MHz.
2.4V ~ 3.6V runs up to 24MHz.
General 8052 family compatible with 12
clocks in one machine cycle.
6 clocks in one machine cycle is also
supported.
Description
The SM5958 series product is an 8 - bit single chip
micro controller with 32KB flash & 1KB SRAM
embedded. It has In-System Programming (ISP)
function and is a derivative of the 8052 micro controller
family.
256 bytes SRAM as standard 8052.
On-chip 768 bytes expanded RAM.
16-bit Data Pointers (DPTR).
One serial peripheral interfaces in full duplex
mode (UART).
SM5958 is a versatile and cost effective controller for
those applications which demand up to 36 I/O pins, or
applications which need up to 32K byte flash memory
either for program or for data or mixed.
-
-
-
-
Synchronous mode, fixed baud rate.
8-bit UART mode, variable baud rate.
9-bit UART mode, fixed baud rate.
9-bit UART mode, variable baud rate.
To program the on-chip flash memory, a commercial
writer is available to do it in parallel programming
method. The on-chip flash memory can be
programmed in either parallel or serial interface with its
ISP feature.
Three 16-bit Timer/Counters (Timer 0, 1, 2).
One watch dog timer (WDT).
One IIC interface (Master / Slave mode).
Two 8-bit/5-bit configurable PWM output
channels.
Ordering Information
SM5958ihhkL yymmv
ISP/IAP functions.
ISP service program space configurable in
N*512 byte (N=0 to 8) size.
Seven interrupt sources with two priority
levels.
Four 8-bit I/O ports and additional one 4-bit
I/O ports.
i: process identifier { W = 2.4V ~ 5.5V}
hh: pin count
k: package type postfix {as table below }
L:PB Free identifier
{No text is Non-PB free, ”P” is PB free}
yy: year
IO PAD ESD over 4KV.
mm: month
Enhance user code protection.
Power management unit for IDLE and power
down modes.
v: version identifier{ A, B,…}
