SM5953
8-Bit Micro-controller
15KB with ISP Flash
& 256B RAM embedded
Product List
SM5953W40PP,
SM5953W44JP,
SM5953W44QP,
Features
Main Flash ROM 15KB
Working voltage 2.4V~5.5V
4.5V ~ 5.5V runs up to 40MHz
2.4V ~ 3.6V runs up to 24MHz
General 8052 family compatible with 12
clocks in one machine cycle
6 clocks in one machine cycle is also
supported
Description
The SM5953 series product is an 8 - bit single chip
micro controller with 15KB flash & 256 bytes SRAM
embedded. It has In-System Programming (ISP)
function and is a derivative of the 8052 micro controller
family.
256 bytes SRAM as standard 8052.
16-bit Data Pointers (DPTR).
One serial peripheral interfaces in full duplex
mode (UART).
SM5953 is a versatile and cost effective controller for
those applications which demand up to 32 I/O pins, or
applications which need up to 15K byte flash memory
either for program or for data or mixed.
-
-
-
-
Synchronous mode, fixed baud rate.
8-bit UART mode, variable baud rate.
9-bit UART mode, fixed baud rate.
9-bit UART mode, variable baud rate.
To program the on-chip flash memory, a commercial
writer is available to do it in parallel programming
method. The on-chip flash memory can be
programmed in either parallel or serial interface with its
ISP feature.
Three 16-bit Timer/Counters. (Timer 0, 1, 2).
One watch dog timer (WDT).
ISP/IAP functions.
ISP service program space configurable in N
(N=0 to 8).
EEPROM function.
Six interrupt sources with two priority levels.
Four 8-bit I/O ports
Ordering Information
SM5953ihhkL yymmv
i: process identifier { W = 2.4V ~ 5.5V}
hh: pin count
IO PAD ESD over 4KV
Enhance user code protection.
Power management unit for IDLE and power
down modes.
k: package type postfix {as table below }
L:PB Free identifier
{No text is Non-PB free，”P” is PB free}
yy: year
mm: month
v: version identifier{ A, B,…}
Tel:021-58998693
www.fosvos.com
Postfix
Package
PDIP
PLCC
P
J
Q
PQFP
FOSVOS TEL: 021-58998693
Specifications subject to change without notice contact your sales representatives for the most recent information.
ISSFD-M074 Ver B SM5953 12/27/2013
- 3 -
