SM59A16U1
8-Bit Micro-controller
64KB with ISP Flash
& 6K+256B RAM embedded
Product List
SM59A16U1U48VP
OB59A16U1U48VP
Features
Architecture
-
Instruction-set compatible with MCS-51
-
1T/2T can be switched on the fly
-
Dual 16-bit Data Pointers (DPTR0 & DPTR1)
-
38 GPIOs (LQFP 48), GPIOs can select four
types (quasi-bidirectional, push-pull, open
drain, input-only),default is quasi-
bidirectional(pull-up)
Clock & Power
-
Operating Voltage: 2.2V ~ 5.5V.
-
Support Xtal, Internal RC Oscillator
(22.1184MHz, 20KHz) and PLL to user select.
-
High speed architecture of 1 clock/machine
cycle (1T), runs up to 25MHz
-
Power management unit for idle and power
down modes.
Memory.
-
64KBytes on-chip flash program memory.
-
On–chip flash memories support ISP/IAP/ICP
and EEPROM functions.
-
ISP service program space configurable in
N*256 byte (N=0 to 16) size.
-
On-chip expandable RAM 6K bytes, 256 bytes
RAM as standard 8052.
-
External RAM addresses up to 64K bytes.
UART Interface.
-
Two serial peripheral interfaces in full duplex
mode (UART0 & UART1),
-
Additional Baud Rate Generator for Serial 0
IIC Interface
-
One IIC interface (Master/Slave mode).
SPI Interface.
-
One SPI interface (Master/Slave mode)
KBI (Keyboard Interface).
-
Keyboard interface (KBI) on port 0 or port 2
(default) for eight more interrupts.
OP Controller
-
2 On-Chip OPA/Comparator.
Interrupt Controller
-
interrupts have four priority levels
-
External interrupt 0, 1
Timer
-
Three 16-bit Timers/Counters. (Timer 0, 1, 2)
-
Programmable watchdog timer (WDT)
Description
The SM59A16U1 is a 1T (one machine cycle per clock)
single-chip 8-bit microcontroller. It has 64KB embedded
Flash for program, and executes all ASM51 instructions
fully compatible with MCS-51.
SM59A16U1 contains 6K+256B on-chip RAM, up to 38
GPIOs (48L Package), various serial interfaces and
many peripheral functions as described below. It can be
programmed via writers. Its on-chip ICE is convenient for
users in verification during development stage.
The high performance of SM59A16U1 can achieve
complicated manipulation within short time. About one
third of the instructions are pure 1T, and the average
speed is 8 times of traditional 8051, the fastest one
among all the 1T 51-series.Its excellent EMI and ESD
characteristics are advantageous for many different
applications.
The SM59A16U1 offers outstanding features, like USB
Interface, high performance PWM for motor control
applications, high speed 10-bit A/D convert for barcode
reader applications. The SM59A16U all features as
below.
Ordering Information
SM59A16U1ihhkL yymmv
i: process identifier { U = 2.2V ~ 5.5V}
hh: pin count
k: package type postfix {as table below }
L:PB Free identifier
{No text is Non-PB free，”P” is PB free}
yy: year
mm: month
v: version identifier{ A, B,…}
Postfix
V
Package
LQFP
Specifications subject to change without notice contact your sales representatives for the most recent information.
ISSFD-M071
Ver A
