SM59A16U1
8-Bit Micro-controller
64KB with ISP Flash
& 6K+256B RAM embedded
1000_0000 means 128 successive “1”
[ ※Greater than 128 will continue to increase])
11 = Enable barcode decoder. [Decode the 8 bits of ADC data (MSB)]
Analysis/count barcode raw data then write the results into SRAM.
The results data format as following:
b7 : convert data
b[6:0]: length
ex: 1000_0111 means 7 successive “1”.
1000_1000 means 8 successive “1”.
1000_0000 means greater then 128 successive “1”
[※Will not increase more than 128] )
BarcodeINF[1:0] Barcode Input Noise Filter
00 = 1 consecutive same value recognize as valid data.
01 = 2 consecutive same value recognize as valid data.
10 = 3 consecutive same value recognize as valid data.
11 = 4 consecutive same value recognize as valid data.
RAWBITNUM Raw Data Bit Number
0 = 10 bit; HW write raw data 10 bit into SRAM.
1 = 8 bit; HW write raw data 8 bit (MSB) into SRAM.
ADCDS The ADC of data select
[1:0] 00 = Compared with the previous first ADC of data.
01 = Compared with the previous second ADC of data.
10 = Compared with the previous third ADC of data.
11 = Compared with the previous fourth ADC of data.
bcdidv Initial digital value of Barcode decoder
bcdidv = 1 after system reset
20.2
Start Address to SRAM Register( ADDR2ML, ADDR2MH )
Mnemonic: ADDR2ML
Address: CBh
7
6
5
4
3
2
1
1
0
Reset
00H
ADDR2M[7:0]
Mnemonic: ADDR2MH
Address: CEh
0
7
6
-
5
4
3
2
Reset
00H
ADDR2M[12:8]
ADDR2M: Starting address of data written to SRAM;
[12:0]
The content of this register will not be updated when barcode controller write data to SRAM.
data written to the address of SRAM arbitrary.
