Electrical specifications
TDA7498L
3
Electrical specifications
3.1
Absolute maximum ratings
Table 3.
Symbol
Absolute maximum ratings
Parameter
Value
Unit
VCC_MAX DC supply voltage for pins PVCCA, PVCCB
44
V
Voltage limits for input pins STBY, MUTE, INNA, INPA,
INNB, INPB, GAIN0, GAIN1
VL_MAX
-0.3 to 3.6
V
Tj_MAX
Tstg
Operating junction temperature
Storage temperature
0 to 150
°C
°C
-40 to 150
Warning: Stresses beyond those listed under “Absolute maximum
ratings” make cause permanent damage to the device. These
are stress ratings only, and functional operation of the device
at these or any other conditions beyond those indicated
under “Recommended operating condition” are not implied.
Exposure to absolute-maximum-rated conditions for
extended periods may affect device reliability. In the real
application, the power supply with the nominal value rated in
the recommended operating conditions, may rise beyond the
maximum operating condition for a short time when no or
very low current is sunk (amplifier in mute state). In this case
the reliability of the device is guaranteed, provided that the
absolute maximum rating is not exceeded.
3.2
3.3
Thermal data
Table 4.
Symbol
Thermal data
Parameter
Min
Typ Max Unit
°C/W
Rth j-case Thermal resistance, junction to case
-
2
3
Recommended operating conditions
Table 5.
Symbol
Recommended operating conditions
Parameter
Min
Typ Max Unit
VCC
Supply voltage for pins PVCCA, PVCCB
Ambient operating temperature
14
-
-
36
85
V
Tamb
-20
°C
8/27
Doc ID 16504 Rev 3
