STM8S003K3 STM8S003F3
Electrical characteristics
Conditions
(1)
Max fHSE/fCPU
Symbol Parameter
Unit
General
Monitored
16 MHz/ 16 MHz/
conditions
frequency band
8 MHz
16 MHz
Conforming to 130 MHz
SAE IEC
61967-2
130 MHz to
5
5
1 GHz
SAE EMI
level
2.5
2.5
SAE EMI level
(1) Data based on characterisation results, not tested in production.
9.3.11.4 Absolute maximum ratings (electrical sensitivity)
Based on three different tests (ESD, DLU and LU) using specific measurement methods, the
product is stressed to determine its performance in terms of electrical sensitivity. For more
details, refer to the application note AN1181.
9.3.11.5 Electrostatic discharge (ESD)
Electrostatic discharges (a positive then a negative pulse separated by 1 second) are applied
to the pins of each sample according to each pin combination. The sample size depends on
the number of supply pins in the device (3 parts*(n+1) supply pin). One model can be simulated:
Human body model. This test conforms to the JESD22-A114A/A115A standard. For more
details, refer to the application note AN1181.
Table 49: ESD absolute maximum ratings
Symbol
Ratings
Conditions
Class Maximum Unit
value(1)
VESD(HBM)
Electrostatic discharge
voltage
TA = 25°C, conforming to
JESD22-A114
A
4000
1000
(Human body model)
V
VESD(CDM)
Electrostatic discharge
voltage
TA LQFP32 package =
25°C, conforming to
SD22-C101
IV
(Charge device model)
DocID018576 Rev 2
87/99
