ST6208C/ST6209C/ST6210C/ST6220C
11 GENERAL INFORMATION
11.1 PACKAGE MECHANICAL DATA
Figure 74. 20-Pin Plastic Dual In-Line Package, 300-mil Width
mm
Min Typ Max Min Typ Max
5.33 0.210
inches
Dim.
A2
A
A
A1
c
L
A1 0.38
0.015
A2 2.92 3.30 4.95 0.115 0.130 0.195
0.36 0.46 0.56 0.014 0.018 0.022
b2 1.14 1.52 1.78 0.045 0.060 0.070
b
eB
b
D1
e
b2
c
0.20 0.25 0.36 0.008 0.010 0.014
24.89 26.16 26.92 0.980 1.030 1.060
D
D
D1 0.13
0.005
e
2.54
0.100
11
10
20
1
eB
10.92
0.430
E1
E1 6.10 6.35 7.11 0.240 0.250 0.280
L
2.92 3.30 3.81 0.115 0.130 0.150
Number of Pins
N
20
Figure 75. 20-Pin Ceramic Side-Brazed Dual In-Line Package
mm
Min Typ Max Min Typ Max
3.63 0.143
inches
Dim.
A
A1 0.38
0.015
B
3.56 0.46 0.56 0.140 0.018 0.022
B1 1.14 12.70 1.78 0.045 0.500 0.070
C
D
0.20 0.25 0.36 0.008 0.010 0.014
24.89 25.40 25.91 0.980 1.000 1.020
D1
22.86
0.900
E1 6.99 7.49 8.00 0.275 0.295 0.315
e
2.54
0.100
G
6.35 6.60 6.86 0.250 0.260 0.270
G1 9.47 9.73 9.98 0.373 0.383 0.393
G2
L
1.14
0.045
2.92 3.30 3.81 0.115 0.130 0.150
S
12.70
4.22
0.500
0.166
Ø
CDIP20W
Number of Pins
20
N
90/104
