L6699
Electrical data
Table 5.
Symbol
Electrical characteristics (continued)
Parameter
Test condition
Min.
Typ.
Max.
Unit
Isourcepk
Peak source current
Peak sink current
Fall time
-0.3
0.8
A
A
Isinkpk
tf
tr
30
60
ns
ns
V
Rise time
UVLO saturation
V
CC = 0 to VCCOn, Isink = 2 mA
1.1
1.5
High-side gate driver (voltages referred to out)
VLVGL
VLVGH
Isourcepk
Isinkpk
tf
Output low voltage
Output high voltage
Peak source current
Peak sink current
Fall time
Isink = 200 mA
Isource = 5 mA
V
V
12.8
-0.3
0.8
13.3
A
A
30
60
22
ns
ns
kΩ
tr
Rise time
HVG-OUT pull-down
1. Values tracking each other.
2. Refer to adaptive deadtime section, Figure 9.
