TSV321-TSV358-TSV324
Absolute Maximum Ratings
2
Absolute Maximum Ratings
Table 1.
Symbol
Key parameters and their absolute maximum ratings
Parameter
Value
Unit
(1)
V
7
1
V
V
Supply Voltage
CC
(2)
V
Differential Input Voltage
id
V
Input Voltage
V
-0.3 to V +0.3
V
i
DD
CC
T
Storage Temperature
Maximum Junction Temperature
-65 to +150
150
°C
°C
stg
T
j
(3)
Thermal Resistance Junction to Ambient
°C/W
250
125
103
120
100
190
SOT23-5
SO-8
SO-14
TSSOP8
TSSOP14
MiniSO-8
R
thja
(4)
2
kV
V
HBM: Human Body Model
(5)
ESD
200
MM: Machine Model
CDM: Charged Device Model
Latch-up Immunity
1.5
200
250
kV
mA
°C
Lead Temperature (soldering, 10s)
Output Short Circuit Duration
(6)
see note
1. All voltages values, except differential voltage are with respect to network terminal.
2. Differential voltages are the non-inverting input terminal with respect to the inverting input terminal. If Vid > 1V, the
maximum input current must not exceed 1mA. In this case (Vid > 1V) an input series resistor must be added to limit input
current.
3. Short-circuits can cause excessive heating. Destructive dissipation can result from simultaneous short-circuit on all
amplifiers.
4. Human body model, 100pF discharged through a 1.5kΩ resistor into pin of device.
5. Machine model ESD, a 200pF cap is charged to the specified voltage, then discharged directly into the IC with no external
series resistor (internal resistor < 5Ω), into pin to pin of device.
6. Short-circuits from the output to VCCcan cause excessive heating. The maximum output current is approximately 80mA,
independent of the magnitude of VCC. Destructive dissipation can result from simultaneous short-circuits on all amplifiers.
Table 2.
Symbol
Operating conditions
Parameter
Value
Unit
V
V
V
Supply Voltage
2.5 to 6
V
V
CC
icm
icm
(1)
(2)
Common Mode Input Voltage Range
Common Mode Input Voltage Range
V
- 0.2 to V + 0.2
DD CC
V
to V
V
DD
CC
T
Operating Free Air Temperature Range
1. At 25°C, for 2.5 ≤ VCC ≤ 6V, Vicm is extended to VDD - 0.2V, VCC + 0.2V.
2. In full temperature range, both Rails can be reached when VCC does not exceed 5.5V.
-40 to + 125
°C
oper
3/15
