32 Mbit Concurrent SuperFlash
SST36VF3203 / SST36VF3204
Data Sheet
TABLE 3: SST36VF3203, 2M
X
16 CSF B
OTTOM
D
UAL
-B
ANK
M
EMORY
O
RGANIZATION
(C
ONTINUED
) (2
OF
2)
SST36VF3203
Block
BA42
BA43
BA44
BA45
BA46
BA47
BA48
BA49
BA50
BA51
Bank 2
BA52
BA53
BA54
BA55
BA56
BA57
BA58
BA59
BA60
BA61
BA62
BA63
Block Size
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
32 KW / 64 KB
Address Range x8
2A0000H—2AFFFFH
2B0000H–2BFFFFH
2C0000H–2CFFFFH
2D0000H–2DFFFFH
2E0000H–2EFFFFH
2F0000H–2FFFFFH
300000H–30FFFFH
310000H–31FFFFH
320000H–32FFFFH
330000H–33FFFFH
340000H–34FFFFH
350000H–35FFFFH
360000H–36FFFFH
370000H–37FFFFH
380000H–38FFFFH
390000H–39FFFFH
3A0000H–3AFFFFH
3B0000H–3BFFFFH
3C0000H–3CFFFFH
3D0000H–3DFFFFH
3E0000H–3EFFFFH
3F0000H–3FFFFFH
Address Range x16
150000H—157FFFH
158000H–15FFFFH
160000H–167FFFH
168000H–16FFFFH
170000H–177FFFH
178000H–17FFFFH
180000H–187FFFH
188000H–18FFFFH
190000H–197FFFH
198000H–19FFFFH
1A0000H–1A7FFFH
1A8000H–1AFFFFH
1B0000H–1B7FFFH
1B8000H–1BFFFFH
1C0000H–1C7FFFH
1C8000H–1CFFFFH
1D0000H–1D7FFFH
1D8000H–1DFFFFH
1E0000H–1E7FFFH
1E8000H–1EFFFFH
1F0000H–1F7FFFH
1F8000H–1FFFFFH
T3.0 1270
