16 Mbit Concurrent SuperFlash + 2/4/8 Mbit SRAM ComboMemory
SST34HF1602C / SST34HF1622C / SST34HF1642C
SST34HF1642D / SST34HF1682D / SST34HF1622S / SST34HF1642S
Advance Information
Chip-Erase
Sector-Erase
Block-Erase
Command Sequence
Command Sequence
Command Sequence
Load data: XXAAH
Address: 5555H
Load data: XXAAH
Address: 5555H
Load data: XXAAH
Address: 5555H
Load data: XX55H
Address: 2AAAH
Load data: XX55H
Address: 2AAAH
Load data: XX55H
Address: 2AAAH
Load data: XX80H
Address: 5555H
Load data: XX80H
Address: 5555H
Load data: XX80H
Address: 5555H
Load data: XXAAH
Address: 5555H
Load data: XXAAH
Address: 5555H
Load data: XXAAH
Address: 5555H
Load data: XX55H
Address: 2AAAH
Load data: XX55H
Address: 2AAAH
Load data: XX55H
Address: 2AAAH
Load data: XX10H
Address: 5555H
Load data: XX30H
Load data: XX50H
Address: SA
Address: BA
X
X
Wait T
Wait T
Wait T
BE
SCE
SE
Chip erased
to FFFFH
Sector erased
to FFFFH
Block erased
to FFFFH
1256 F25.0
Note: X can be V or V but no other value.
IL
IH,
FIGURE 26: ERASE COMMAND SEQUENCE
©2004 Silicon Storage Technology, Inc.
S71256-00-000
3/04
33
