Table 4. Sector Address Table–S29GL128N (Continued)
8-Bit
Sector Size
16-bit
Address Range
(in hexadecimal)
Address Range
(Kbytes/
Sector
A22–A16
(in hexadecimal)
Kwords)
128/64
128/64
128/64
128/64
128/64
128/64
128/64
128/64
128/64
128/64
128/64
128/64
128/64
128/64
128/64
128/64
128/64
SA111
SA112
SA113
SA114
SA115
SA116
SA117
SA118
SA119
SA120
SA121
SA122
SA123
SA124
SA125
SA126
SA127
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
1
0
0
0
0
1
1
1
1
0
0
0
0
1
1
1
1
1
0
0
1
1
0
0
1
1
0
0
1
1
0
0
1
1
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0DE0000–0DFFFFF
0E00000–0E1FFFF
0E20000–0E3FFFF
0E40000–0E5FFFF
0E60000–0E7FFFF
0E80000–0E9FFFF
0EA0000–0EBFFFF
0EC0000–0EDFFFF
0EE0000–0EFFFFF
0F00000–0F1FFFF
0F20000–0F3FFFF
0F40000–0F5FFFF
0F60000–0F7FFFF
0F80000–0F9FFFF
0FA0000–0FBFFFF
0FC0000–0FDFFFF
0FE0000–0FFFFFF
06F0000–06FFFFF
0700000–070FFFF
0710000–071FFFF
0720000–072FFFF
0730000–073FFFF
0740000–074FFFF
0750000–075FFFF
0760000–076FFFF
0770000–077FFFF
0780000–078FFFF
0790000–079FFFF
07A0000–07AFFFF
07B0000–07BFFFF
07C0000–07CFFFF
07D0000–07DFFFF
07E0000–07EFFFF
07F0000–07FFFFF
Autoselect Mode
The autoselect mode provides manufacturer and device identification, and sector
group protection verification, through identifier codes output on DQ7–DQ0. This
mode is primarily intended for programming equipment to automatically match a
device to be programmed with its corresponding programming algorithm. How-
ever, the autoselect codes can also be accessed in-system through the command
register.
When using programming equipment, the autoselect mode requires VID on ad-
dress pin A9. Address pins A6, A3, A2, A1, and A0 must be as shown in Table 5.
In addition, when verifying sector protection, the sector address must appear on
the appropriate highest order address bits (see Table 2). Table 5 shows the re-
maining address bits that are don’t care. When all necessary bits have been set
as required, the programming equipment may then read the corresponding iden-
tifier code on DQ7–DQ0.
To access the autoselect codes in-system, the host system can issue the autose-
lect command via the command register, as shown in Table 12 and Table 13. This
method does not require VID. Refer to the Autoselect Command Sequence section
for more information.
44
S29GLxxxN MirrorBitTM Flash Family
27631A4 May 13, 2004
