2003/2/28 ver 0.1
SN11086
6.3 DC electrical characteristics
Table 6
symbol
VDI
parameter
USB differential input sensitivity
test condition value
unit
V
0.2 (min)
| (D+) – (D-) |
VCM
USB differential common mode
range
Included VDI 0.8 (min)
V
range
2.5 (max)
0.8 (min)
2.0 (max)
VSE
USB single ended receiver
V
threshold
VIH
VIL
VOH
VOL
IIL
high level input voltage
low level input voltage
high level output voltage
low level output voltage
low level input current
2.0 (min)
V
V
V
V
0.8 (max)
IOH = -4 mA 2.3 (min)
IOL= 4 mA
VI = 0 V
0.5 (max)
RSTN pin :
- 50.0 (max)
µA
the other pins : - 3.0 (max)
3.0 (max)
IIH
high level input current
input supply current
VI = 3.6 V
µA
IDD
20 (max)
20 (max)
mA
Isuspend supply current in suspend
µA
6.4 AC electrical characteristics
6.4.1 USB transceiver signal (full speed mode)
Table 7
symbol
parameter
test condition
min
4
max
20
unit
transition rise time for DP or DM
transition fall time for DP or DM
rise / fall time matching
signal crossover voltage
Tr
ns
ns
%
V
Tf
4
20
Trfm
Vo(crs)
(Tr / Tf ) * 100
90
1.3
110
2.0
6.4.2 Operation clocks
Table 8
symbol
parameter
value
unit
10
