5th Generation Hi-Speed USB Flash Media and CIR Controller with Integrated Card Power FETs
Datasheet
Chapter 3 Pin Table
3.1
128-Pin Package
Table 3.1 USB2231/USB2232 128-Pin Package
CompactFlashINTERFACE (28 Pins)
CF_D0
CF_D4
CF_D1
CF_D5
CF_D2
CF_D6
CF_D3
CF_D7
CF_D8
CF_D9
CF_D10
CF_D14
CF_IRQ
CF_nCS1
CF_nCD1
CF_D11
CF_D12
CF_nIOR
CF_IORDY
CF_SA1
CF_D13
CF_nIOW
CF_nCS0
CF_SA2
CF_D15
CF_nRESET
CF_SA0
CF_nCD2
SmartMedia INTERFACE (17 Pins)
SM_D0
SM_D4
SM_D1
SM_D5
SM_D2
SM_D3
SM_D7
SM_D6
SM_nRE
SM_nCE
SM_ALE
SM_nWP
SM_nWPS
SM_CLE
SM_nB/R
SM_nWE
SM_nCD
Memory Stick INTERFACE (7 Pins)
MS_BS
MS_D1
MS_SDIO/MS_D0
MS_D2
MS_SCLK
MS_INS
MS_D3
SD INTERFACE (7 Pins)
SD_CMD
SD_DAT2
SD_CLK
SD_DAT0
SD_nWP
SD_DAT1
SD_DAT3
USB INTERFACE (10 Pins)
USBDP
USBDM
VSSPLL
XTAL2
ATEST
RBIAS
VSSA
VDD18PLL
XTAL1/CLKIN
VDDA33
