The transmit queue priority is based on the packet type and device configuration as shown in
Figure 6.5. Refer to Section 13.3.3.16, "Switch Engine Global Ingress Configuration Register
(SWE_GLOBAL_INGRSS_CFG)," on page 329 for definitions of the configuration bits.
Get Queue
Y
Packet from Host
N
DA Highest
Priority
N
Y
wait for ALR result
Y
N
ALR Static Bit
N
VL Higher
Priority
Y
VLAN Enable &
Packet is
Y
Tagged
N
Y
Packet is IPv4/v6
& Use IP
N
VLAN Enable &
Packet is
Tagged
Y
Y
Packet is IPv 4
N
N
Y
N
Use Precedence
Resolved Priority =
Default Priority[Source
Port]
Resolved Priority =
Priority Regen[VLAN
Priority]
Resolved Priority =
IP Precedence
Resolved Priority =
DIFFSERV[TOS]
Resolved Priority =
DIFFSERV[TC]
Queue =
Queue =
ALR Priority
Traffic Class[Resolved Priority]
Get Queue Done
Figure 6.5 Switch Engine Transmit Queue Calculation
