High-Performance Single-Chip 10/100 Ethernet Controller with HP Auto-MDIX
Datasheet
.
System Memory
System Memory
System
Peripherals
Magnetics
Ethernet
Microprocessor/
Microcontroller
System Bus
LAN9218
LEDS/GPIO
25MHz
XTAL
EEPROM
(Optional)
Figure 1.1 System Block Diagram
The SMSC LAN9218 integrated 10/100 MAC/PHY controller is a peripheral chip that performs the
function of translating parallel data from a host controller into Ethernet packets. The LAN9218 Ethernet
MAC/PHY controller is designed and optimized to function in an embedded environment. All
communication is performed with programmed I/O transactions using the simple SRAM-like host
interface bus.
The diagram shown above, describes a typical system configuration of the LAN9218 in a typical
embedded environment.
The LAN9218 is a general purpose, platform independent, Ethernet controller. The LAN9218 consists
of four major functional blocks. The four blocks are:
10/100 Ethernet PHY
10/100 Ethernet MAC
RX/TX FIFOs
Host Bus Interface (HBI)
1.1
Compatibility with First-generation LAN9118 Family Devices
The LAN9218 is driver-, register-, and footprint-compatible with previous generation LAN9118 Family
devices. Drivers written for these products will work with the LAN9218. However, in order to support
HP Auto-MDIX, other components such as the magnetics and the passive components around the
magnetics need to change, and supporting these changes does require a minor PCB change. A
reference design for the LAN9218 will be available on SMSC’s website.
Revision 1.5 (07-18-06)
SMSC LAN9218
DATA1S0HEET
