High-Performance Single-Chip 10/100 Ethernet Controller with HP Auto-MDIX and Industrial Temperature Support
Datasheet
5.3.23
E2P_CMD – EEPROM Command Register
Offset:
B0h
Size:
32 bits
This register is used to control the read and write operations with the Serial EEPROM.
BITS
DESCRIPTION
TYPE
DEFAULT
31
EPC Busy: When a 1 is written into this bit, the operation specified in the
EPC command field is performed at the specified EEPROM address. This
bit will remain set until the operation is complete. In the case of a read this
means that the host can read valid data from the E2P data register. The
E2P_CMD and E2P_DATA registers should not be modified until this bit is
cleared. In the case where a write is attempted and an EEPROM is not
present, the EPC Busy remains busy until the EPC Time-out occurs. At that
time the busy bit is cleared.
SC
0
Note:
EPC busy will be high immediately following power-up or reset.
After the EEPROM controller has finished reading (or attempting to
read) the MAC address from the EEPROM the EPC Busy bit is
cleared.
Revision 1.8 (06-06-07)
92
SMSC LAN9218i
DATASHEET
