Power Consumption (Device and System Components)
This section provides typical power consumption values for a complete Ethernet interface based on
the LAN9218i, including the power dissipated by the magnetics and other passive components. All of
these values are preliminary.
Please refer to the SMSC application note AN14.10 - “Migrating from LAN9118 to the LAN9218I”, that
can be found on SMSC’s web site www.smsc.com, which contains additional details on magnetics and
other components used.
Note: The power measurements list below were taken under the following conditions:
Temperature: ................................................................................................................................... +25°C
Device VDD:................................................................................................................................... +3.30V
Table 7.2 Power Consumption Device and System Components
Total Power - Typical (mW)
MODE
10BASE-T Operation
D0, 10BASE-T /w traffic
D0, Idle
612
620
508
65
D1, Idle
D2, Energy Detect Power Down
D2, General Power Down
100BASE-TX Operation
D0, 100BASE-TX /w traffic
D0, Idle
11
540
577
439
65
D1, Idle
D2, Energy Detect Power Down
D2, General Power Down
11
