16-bit High-Performance Single-Chip 10/100 Ethernet Controller with HP Auto-MDIX
Datasheet
5.4.1
MAC_CR—MAC Control Register
Offset:
1
Attribute:
Size:
R/W
Default Value:
00040000h
32 bits
This register establishes the RX and TX operation modes and controls for address filtering and packet
filtering.
BITS
DESCRIPTION
31
Receive All Mode (RXALL). When set, all incoming packets will be received and passed on to the
address filtering Function for processing of the selected filtering mode on the received frame. Address
filtering then occurs and is reported in Receive Status. When reset, only frames that pass Destination
Address filtering will be sent to the Application.
30-24
23
Reserved
Disable Receive Own (RCVOWN). When set, the MAC disables the reception of frames when TXEN
is asserted. The MAC blocks the transmitted frame on the receive path. When reset, the MAC receives
all packets the PHY gives, including those transmitted by the MAC.This bit should be reset when the
Full Duplex Mode bit is set.
22
21
Reserved
Loopback operation Mode (LOOPBK). Selects the loop back operation modes for the MAC. This is
only for full duplex mode
1’b0: Normal: No feedback
1’b1: Internal: Through MII
In internal loopback mode, the TX frame is received by the Internal MII interface, and sent back to
the MAC without being sent to the PHY.
Note:
When enabling or disabling the loopback mode it can take up to 10μs for the mode change
to occur. The transmitter and receiver must be stopped and disabled when modifying the
LOOPBK bit. The transmitter or receiver should not be enabled within10μs of modifying the
LOOPBK bit.
20
19
Full Duplex Mode (FDPX). When set, the MAC operates in Full-Duplex mode, in which it can transmit
and receive simultaneously. In Full-Duplex mode, the heartbeat check is disabled and the heartbeat
fail status should thus be ignored.
Pass All Multicast (MCPAS). When set, indicates that all incoming frames with a Multicast destination
address (first bit in the destination address field is 1) are received. Incoming frames with physical
address (Individual Address/Unicast) destinations are filtered and received only if the address matches
the MAC Address.
18
17
16
15
14
Promiscuous Mode (PRMS). When set, indicates that any incoming frame is received regardless of
its destination address.
Inverse filtering (INVFILT). When set, the address check Function operates in Inverse filtering mode.
This is valid only during Perfect filtering mode.
Pass Bad Frames (PASSBAD). When set, all incoming frames that passed address filtering are
received, including runt frames, collided frames or truncated frames caused by buffer underrun.
Hash Only Filtering mode (HO). When set, the address check Function operates in the Imperfect
Address Filtering mode both for physical and multicast addresses
Reserved
SMSC LAN9217
Revision 1.5 (07-18-06)
