PIN DESCRIPTION
BUFFER TYPE PER PIN
Table 1 - DESCRIPTION OF PIN FUNCTIONS
BUFFER
TQFP
PIN #
NAME
SYMBOL
TYPE
DESCRIPTION
HOST PROCESSOR INTERFACE
46-49 Data Bus 0- D0-D7
IO12
The data bus connection used by the host
51-54
7
microprocessor to transmit data to and from the chip.
These pins are in a high-impedance state when not in
the output mode.
42
43
44
nI/O Read
nI/O Write
nIOR
nIOW
AEN
IS
IS
IS
This active low signal is issued by the host micropro-
cessor to indicate an I/O read operation.
This active low signal is issued by the host micropro-
cessor to indicate an I/O write operation.
Active high Address Enable indicates DMA operations
on the host data bus. Used internally to qualify
appropriate address decodes.
Address
Enable
26-32 Address
39-41, Bus
95
A0-A10
I
These host address bits determine the I/O address to
be accessed during nIOR and nIOW cycles. These
bits are latched internally by the leading edge of nIOR
and nIOW. All internal address decodes use the full
A0 to A10 address bits.
19,50, DMA
DRQ_A
DRQ_B
DRQ_C
O12
These active high outputs are the DMA request for
byte transfers of data between the host and the chip.
These signals are cleared on the last byte of the data
transfer by the nDACK signal going low (or by nIOR
going low if nDACK was already low as in demand
mode).
97
Request
A, B, C
20,34, nDMA
nDACK_A
nDACK_B
nDACK_C
IS
IS
These are active low inputs acknowledging the
request for a DMA transfer of data between the host
and the chip. These inputs enable the DMA read or
write internally.
This signal indicates that DMA data transfer is
complete. TC is only accepted when nDACK_x is
low. In AT and PS/2 model 30 modes, TC is active
high and in PS/2 mode, TC is active low.
94
Acknowl-
edge
A, B, C
Terminal
Count
33
TC
17,
Interrupt
IRQ_A
IRQ_C
IRQ_D
O12/OD12 Interrupt requests from a logical device or IRQIN are
output on one of the IRQA-H signals. Refer to the
configuration registers section for additional
information.
35-38, Request
22
A, C, D,
E, F, and H IRQ_E
IRQ_F
If EPP or ECP Mode is enabled this output is pulsed
low and released to allow sharing of interrupts.
IRQ_H
25
55
Chip Select nCS
Input
I
This active low input serves as an external decoder
for address lines above A10.
Reset
RESET
IS
This active high signal resets the chip and must be
valid for 500ns minimum. The effect on the internal
registers is described in the appropriate section. The
configuration registers are not affected by this reset.
This pin is pulled low to extend the read/write
command. IOCHRDY can used by the IRCC and by
the Parallel Port in EPP mode.
98
I/O Channel IOCHRDY
OD12
Ready
(Note4)
FLOPPY DISK INTERFACE
IS Raw serial bit stream from the disk drive, low active.
Each falling edge represents a flux transition of the
encoded data.
O12/OD12 This active low high current driver allows current to
flow through the write head. It becomes active just
prior to writing to the diskette.
14
8
nRead Disk nRDATA
Data
nWrite
Gate
nWGATE
SMSC DS – FDC37N769
Page 8 of 137
Rev. 02-16-07
DATASHEET
