Multiple Channel 1°C Temperature Sensor with Beta Compensation
Datasheet
REVISION HISTORY
REVISION
-
DESCRIPTION
DATE
-
RELEASED BY
-
3
SEE SPEC FRONT PAGE FOR REVISION HISTORY
D
PIN 1 IDENTIFIER
AREA (D/2 X E1/2)
5
e
c
E
3
E1
SEE DETAIL "A"
2
8X b
TOP VIEW
END VIEW
A2
A
C
SEATING PLANE
A1
ccc
C
SIDE VIEW
3-D VIEW
NOTES:
1. ALL DIMENSIONS ARE IN MILLIMETER.
2. TOLERANCE ON THE TRUE POSITION OF THE LEADS IS ± 0.065mm MAXIMUM.
3. PACKAGE BODY DIMENSIONS "D" AND "E1" DO NOT INCLUDE MOLD PROTRUSIONS OR FLASH.
MAXIMUM MOLD PROTRUSIONS OR FLASH IS 0.15 mm (0.006 INCHES) PER END AND SIDE.
DIMENSIONS "D" AND "E1" ARE DETERMINED AT DATUM PLANE "H".
4. DIMENSION FOR FOOT LENGTH "L" IS MEASURED AT THE GAUGE PLANE 0.25mm ABOVE THE
SEATING PLANE.
H
C
GAUGE PLANE
5. DETAILS OF PIN 1 IDENTIFIER ARE OPTIONAL, BUT MUST BE LOCATED WITHIN THE ZONE
INDICATED.
0.25
SEATING PLANE
4
L
0° - 8°
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN MILLIMETERS
AND TOLERANCES ARE:
THIRD ANGLE PROJECTION
80 ARKAY DRIVE
HAUPPAUGE, NY 11788
USA
DECIMAL
X.X ±0.1
ANGULAR
±1°
L1
X.XX ±0.05
X.XXX ±0.025
TITLE
NAME
DATE
DIM AND TOL PER ASME Y14.5M - 1994
MATERIAL
PACKAGE OUTLINE
8 PIN TSSOP, 3x3 MM BODY, 0.65 MM PITCH
DETAIL "A"
SCALE: 3/1
DRAWN
-
S.K.ILIEV
7/05/04
FINISH
CHECKED
DWG NUMBER
REV
-
S.K.ILIEV
7/05/04
7/07/04
D
MO-8-TSSOP-3x3
STD COMPLIANCE
APPROVED
SCALE
SHEET
PRINT WITH "SCALE TO FIT"
DO NOT SCALE DRAWING
S.K.ILIEV
1:1
JEDEC: MO-187 / D
1 OF 1
Figure 9.4 8-Pin MSOP / TSSOP Package
Revision 1.41 (02-23-12)
SMSC EMC1412
DATA4S2HEET
