1°C Triple SMBus Sensor with Resistance Error Correction
Datasheet
4.10
Remote 2 Status Register
The Remote 2 Status register is a read only register that stores the operational status of the remote 2
temperature.
Table 4.5 Remote 2 Status Register
REMOTE 2 STATUS REGISTER
BIT
NAME
FUNCTION
7-3
2
Reserved
R2HIGH
R2LOW
R2THRM
1 when Remote 2 Temperature High Limit is exceeded
1 when Remote 2 Temperature Low Limit is exceeded
1 when Remote 2 THERM limit is exceeded
1
0
Bits 2 and 1 indicate that the Remote 2 temperature is above or below its high or low limits. See
Section 4.13, "Limit Registers," on page 17 for detail on the limits are compared. Bits 0 indicates that
the Remote 2 temperature has exceeded its THERM limit. If bit 0 goes high the ADDR/THERM signal
will be asserted.
Bits 2 and 1 will be cleared individually when the status register is read provided that the error condition
for that bit is gone.
4.11
Configuration Register
The configuration register controls the functionality of the temperature measurements.
Table 4.6 Configuration Register
CONFIGURATION REGISTER
BIT
NAME
MASK1
FUNCTION
DEFAULT
7
0 = ALERT enabled
1 = ALERT disabled
0
6
5
RUN/STOP
0 = Active mode (continuously running)
1 = Standby mode
0
0
ALERT or THERM2
0 = ALERT
1 = THERM2
4 – 3
2
Reserved
0
0
Temperature Range
Select
0 = 0°C to 127°C
1 = -64°C to 191°C
1
0
Reserved
APD
0
0
0 = Anti-Parallel Diode enabled
1 = Anti-Parallel Diode disabled
Bit 7 is used to mask the ALERT/THERM2 output. When this bit is set to 0, any out of limit condition
will assert ALERT/THERM2. This bit is ignored if the ALERT/THERM2 pin is configured as THERM2 signal
by bit 5.
Revision 1.1 (01-19-07)
