10 Mbps ARCNET (ANSI 878.1) Controller with 2Kx8 On-Board RAM
Datasheet
Table 5.1 - Typical Media
NOMINAL
ATTENUATION PER 1000 FT.
CABLE TYPE
IMPEDANCE
AT 5 MHZ
RG-62 Belden #86262
5.5dB
93Ω
75Ω
RG-59/U Belden #89108
7.0dB
5.5dB
RG-11/U Belden #89108
75Ω
IBM Type 1* Belden #89688
7.0dB
150Ω
100Ω
105Ω
IBM Type 3* Telephone Twisted Pair Belden #1155A
COMCODE 26 AWG Twisted Pair Part #105-064-703
17.9dB
16.0dB
Note*:
Non-plenum-rated cables of this type are also available.
SMSC COM20022I
Page 29
Revision 02-27-06
