DATA SHEET • CX77107
PA MODULE FOR CDMA / PCS (1850–1910 MHZ)
Table 5. Electrical Specifications for CDMA Recommended Operating Conditions (1)
Characteristics
Symbol
Condition
Minimum
Maximum
Unit
VCONT ≥ 2.5 V
PO = 16 dBm
GLOW
21.0
29.5
Gain conditions
Digital Mode
dB
VCONT ≤ 0.5 V
PO = 28 dBm
GHIGH
24.5
—
33.0
–44
–44
–56
–56
VCONT ≥ 2.5 V
PO ≤ 16 dBm
ACP1LOW
ACP1HIGH
ACP3LOW
ACP3HIGH
1.25 MHz offset
2.25 MHz offset
VCONT ≤ 0.5 V
PO ≤ 28 dBm
—
(2) (3) (4)
Adjacent Channel Power
Harmonic Suppression
dBc
dBc
VCONT ≥ 2.5 V
PO ≤ 16 dBm
—
VCONT ≤ 0.5 V
PO ≤ 28 dBm
—
Second
Third
FO2
PO ≤ 28 dBm
PO ≤ 28 dBm
PO ≤ 28 dBm
—
—
—
—
—
—
–30
–40
FO3
Noise Power in RX Band 1840-1895 MHz
Noise Figure
RxBN
NF
–136.0
7.0
dBm/Hz
dB
Input Voltage Standing Wave Ratio (VSWR)
VSWR
—
2.5:1
—
5:1 VSWR
All phases
Stability (Spurious output)
S
—
–70.0
—
dBc
(5)
Ruggedness – No damage
Ru
PO ≤ 28 dBm
10:1
VSWR
(1)
Per Table 2, unless otherwise specified.
(2)
ACP is specified per IS95 as the ratio of the total in-band power (1.23 MHz BW) to adjacent power in a 30 kHz BW.
(3)
CDMA2000 is configured as DCCH = 9600, SCHO = 9600, PCH (Walsh 0) = –3.75 dB, and Peak-to-Average Ratio (CCDF = 1%) = 4.5 dB. For CDMA2000, 0.5 dB back-off in output power is
required.
(4)
(5)
Worst case ACPR is –43dBc at +85 °C, VCC = 3.2 V.
All phases, time = 10 seconds.
