ST7669V
9.1.73 TEMPSEL: Temp. Set(F4H)
Command
A0
/RD /WR D7
D6
D5
D4
D3
D2
D1
D0
Hex
(F4h)
0
1
0
1
1
1
1
0
1
0
0
TEMPSEL
MT1x : (-24 oC to -32 oC)
MT0x : (-32 oC to -40 oC)
MT3x : (-8 oC to -16 oC)
MT2x : (-16 oC to -24 oC)
MT5x : (8 oC to 0 oC)
MT4x : (0 oC to -8 oC)
MT7x : (24 oC to16 oC)
MT6x : (16 oC to 8 oC)
MT9x : (40 oC to 32 oC)
MT8x : (32 oC to 24 oC)
MTBx : (56 oC to 48 oC)
MTAx : (48 oC to 40 oC)
MTDx : (72 oC to 64 oC)
MTCx : (64 oC to 56 oC)
MTFx : (87 oC to 80 oC)
MTEx : (80 oC to 72 oC)
1st parameter
2nd parameter
3rd parameter
4th parameter
5th parameter
6th parameter
7th parameter
8th parameter
1
1
1
1
1
1
1
1
1
0
MT13 MT12 MT11 MT10 MT03 MT02 MT01 MT00
MT33 MT32 MT31 MT30 MT23 MT22 MT21 MT20
MT53 MT52 MT51 MT50 MT43 MT42 MT41 MT40
MT73 MT72 MT71 MT70 MT63 MT62 MT61 MT60
MT93 MT92 MT91 MT90 MT83 MT82 MT81 MT80
MTB3 MTB2 MTB1 MTB0 MTA3 MTA2 MTA1 MTA0
MTD3 MTD2 MTD1 MTD0 MTC3 MTC2 MTC1 MTC0
MTF3 MTF2 MTF1 MTF0 MTE3 MTE2 MTE1 MTE0
1
1
1
1
1
1
1
0
0
0
0
0
0
0
NOTE: “-“ Don’t care
Description
This command defines temperature gradient compensation coefficient. For this command
detail description and operation, please see Section 7.9.
Parameter n
MT n 3
MT n 2
MT n 1
MT n 0
Voltage / oC
( Tolerance: ±3mV/ oC )
0
1
0
0
0
0
:
0
0
0
0
:
0
0
1
1
:
0
1
0
1
:
0 mv / oC
-5 mv / oC
-10 mv / oC
-15 mv / oC
:
2
3
:
:
:
:
:
:
:
:
:
:
:
:
:
12
13
14
15
1
1
1
1
1
1
1
1
0
0
1
1
0
1
0
1
-60 mv / oC
-65 mv / oC
-70 mv / oC
-75 mv / oC
Restriction
Ver 1.3
175/208
6/4/2008
