ST7669V
9.1.61 AutoLoadSet : mask rom data auto re-load control(D7H)
Command
A0 /RD /WR
D7
1
D6
1
D5
0
D4
1
D3
0
D2
1
D1
1
D0
1
Hex
(D7h)
-
0
1
1
1
0
0
AutoLoadSet
Parameter
EXTE
OTPBE
-
ARD
-
-
-
-
NOTE: “-“ Don’t care
Description
Mask rom data auto re-load control
EXTE : External command enable (OTPC bit), 1: Enable, 0: Disable
OTPBE: OTPB auto-read enable (OTPC bit), 1: Enable, 0: Disable.
ARD: OTPB/OTPC auto read enable control, 1: Disable OTPB/OTPC auto read.
0: Enable OTPB/OTPC auto read.
Restriction
Register
Status
Availability
Yes
Availability
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
Yes
Yes
Default
Status
Default Value
EXTE
ARD
Power On Sequence
S/W Reset
0
0
0
0
0
0
H/W Reset
Flow Chart
Ver 1.3
158/208
6/4/2008
