ST7628
9.1.12 SLPOUT: Sleep Out (11h)
Command
SLPOUT
A0
/RD /WR
D7
D6
D5
D4
D3
D2
D1
D0
Hex
0
0
0
1
0
0
0
1
(11h)
0
1
0
Parameter
No Parameter
Description
This command turns off sleep mode. In this mode the DC/DC converter is enabled, Internal
display oscillator is started, and panel scanning is started.
(IfꢀDISPONꢀ29hꢀisꢀset)
MemoryꢀContents
COM/SEGꢀOutput
Memoryꢀscanꢀoperation
DCꢀchargeꢀinꢀtheꢀcapacitor
STOPꢀ(Blankꢀdisplay)
0V
CHARGE
LCDꢀDrivingꢀvoltageꢀ(Plus)
LCDꢀDrivingꢀvoltage(Minus)
InternalꢀOscillator
0V
0V
STOP
Restriction
This command has no effect when module is already in sleep out mode. Sleep Out Mode can
only be exit by the Sleep In Command (10h).
It will be necessary to wait 5msec before sending next command, this is to allow time for the
supply voltages and clock circuits to stabilize.
The display module loads all display supplier’s factory default values to the registers during this
5msec and there cannot be any abnormal visual effect on the display image if factory default
and register values are same when this load is done and when the display module is already
Sleep Out –mode.
The display module is doing self-diagnostic functions during this 5msec. See also section 7.10.
It will be necessary to wait 120msec after sending Sleep In command (when in Sleep Out mode)
before Sleep Out command can be sent.
Register
Status
Availability
Yes
Availability
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
Yes
Yes
Default
Status
Default Value
Power On Sequence
Sleep in mode
Sleep in mode
Sleep in mode
S/W Reset
H/W Reset
Ver 1.4
92/213
2008/08
SITRONIX [ SITRONIX TECHNOLOGY CO., LTD. ]
