ST7628
Booster setting
Booster Efficiency
Vg source
8x
8x
8x
01
01
01
From VDD2x2
From VDD2x2
From VDD2x2
EPCTIN
0
0
0
OTP selection
Disable
Disable
Disable
Frame Frequency in Normal Color
(FA/FB/FC/FD)
46Hz/61.5Hz/77Hz/82Hz 46Hz/61.5Hz/77Hz/82Hz
46Hz/61.5Hz/77Hz/82Hz
Frame Frequency in 8-Color (Idle)
(F8A/F8B/F8C/F8D)
Temperature Range
(TA/TB/TC)
46Hz/61.5Hz/77Hz/82Hz 46Hz/61.5Hz/77Hz/82Hz
46Hz/61.5Hz/77Hz/82Hz
-16℃/0℃/48℃
-16℃/0℃/48℃
-16℃/0℃/48℃
Temperature Hysteresis (TH)
TEMPSEL
5℃
5℃
5℃
Refer to 9.1.72
Refer to 9.1.72
Refer to 9.1.72
Note. Some of above default values can be modified by customer after OTP writing.
Please refer to OTPB related register list for the content of OTP.
