ST7628
Write(COMMAND, 0xCD );
//ID2
Write(DATA, 0x80 );
Write(COMMAND, 0xB5 );
Write(DATA, 0x01);
// N-Line
// RST, 2-line inversion
// Analog circuit setting
//
Write(COMMAND,0xD0);
Write(DATA,0x1D);
Write(COMMAND,0xD7);
Write(DATA,0x9F);
//Auto read Set
//OTPB Disable
Write(COMMAND,0xB4);
Write(DATA,0x18);
//PTL Mode Select
//PTLMOD ꢃ Normal Mode
}
void Fine_Tune_Vop(void)
{
//------------------------------------- Show Map -----------------------------------------------
Show_Image(); //Display a image
//------------------------------------ Display ON -----------------------------------------------
Write(COMMAND, 0x29 ); // Display On
//--------------------------------Fine tune Vop offset----------------------------------------
Write( COMMAND, 0xC1);
//Fine tuning Vop here by command
or
0xc1(VopOffsetInc),0xc2(VopOffsetDec).
Write( COMMAND, 0xC2);
Note
}
void OTP_Writing(void)
{
//--------------------------------Display OFF----------------------------------------
Write(COMMAND, 0x28 );
Delayms(50);
// Display Off
// delay 50ms
//--------------------------------OTP writing----------------------------------------
Write( COMMAND, 0x00F0 );
Write( DATA, 0x0012 );
Write( DATA, 0x0012 );
// Keep Frame Rate with 77Hz
Ver 1.4
211/213
2008/08
