9.1.59 AutoLoadSet : mask rom data auto re-load control(D7H)
Command
AutoLoadSet
Parameter
A0
0
/RD /WR
D7
1
D6
1
D5
0
D4
1
D3
0
D2
1
D1
1
D0
1
Hex
(D7h)
-
1
1
0
0
OTPBE
1
EXTE
0
ARD
1
1
1
1
NOTE: “-“ Don’t care
Mask rom data auto re-load control
Description
EXTE : External command enable (OTP bit), 1: enable, 0: disable.
OTPBE: OTPB auto-read enable (OTP bit) , 1: enable, 0: disable.
ARD : OTP auto-read enable control, 1: Disable OTP auto-read,
0: Enable OTP auto-read
Restriction
Register
Status
Availability
Yes
Availability
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
Yes
Yes
Default
Status
Default ValueD[7:0]
Power On Sequence
S/W Reset
00h
00h
00h
H/W Reset
Flow Chart
