ST7628
9.1.54 V3SorcSel: FV3 with Bst2x control(CBH)
Command
A0
0
/RD /WR
D7
1
D6
1
D5
0
D4
0
D3
1
D2
0
D1
1
D0
1
Hex
(CBh)
1
1
0
0
V3SorcSel
-
1
-
-
-
-
-
-
-
2BT0
Parameter
NOTE: “-“ Don’t care
Description
2BT0=0: Vg source comes from VDD2 ;
2BT0=1: Vg source comes from 2-times charge pump.
Restriction
Register
Status
Availability
Availability
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
Yes
Yes
Yes
Default
Status
Default Value (2BT0)
Power On Sequence
01h
01h
01h
S/W Reset
H/W Reset
Flow Chart
Ver 1.4
161/213
2008/08
