ST7628
9.1.33 IDMOFF: Idle Mode Off (38h)
Command
IDMOFF
A0
/RD /WR
D7
D6
D5
D4
D3
D2
D1
D0
Hex
0
0
1
1
1
0
0
0
(38h)
0
1
0
Parameter
No Parameter
Description
This command is used to recover from Idle mode on.
There will be no abnormal visible effect on the display mode change transition.
In the idle off mode,
1. LCD can display maximum 65536 colors.
2. Normal frame frequency is applied.
Restriction
Register
This command has no effect when module is already in idle off mode.
Status
Availability
Yes
Availability
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
Yes
Yes
Default
Status
Default Value
Power On Sequence
Idle mode off
Idle mode off
Idle mode off
S/W Reset
H/W Reset
Flow Chart
Ver 1.4
134/213
2008/08
SITRONIX [ SITRONIX TECHNOLOGY CO., LTD. ]
