ST7628
9.1.30 TEON: Tearing Effect Line ON (35h)
Command
A0
0
/RD /WR
D7
0
D6
0
D5
1
D4
1
D3
0
D2
1
D1
0
D0
1
Hex
TEON
(35h)
1
1
0
0
-
-
-
-
-
-
-
M
1
Parameter
NOTE: “-“ Don’t care
This command is used to turn ON the Tearing Effect output signal from the TE signal line. This output is not
affected by changing MADCTR bit ML.
Descriptio
n
The Tearing Effect Line On has one parameter, which describes the mode of the Tearing Effect
Output Line. (“-“=Don’t Care).
When M=0:
The Tearing Effect Output Line consists of V-Blanking information only:
When M=1:
The Tearing Effect Output Line consists of both V-Blanking and H-Blanking information:
See section 7.3.8 for more information.
Note: During Sleep In Mode with Tearing Effect Line On, Tearing Effect Output pin will be active Low.
Restriction This command has no effect when Tearing Effect output is already OFF.
Register
Status
Availability
Yes
Availability
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
Yes
Yes
Default
Status
Default Value
Power On Sequence
Tearing effect off & M=0
Tearing effect off & M=0
Tearing effect off & M=0
S/W Reset
H/W Reset
Ver 1.4
128/213
2008/08
SITRONIX [ SITRONIX TECHNOLOGY CO., LTD. ]
