EFR32MG13 Mighty Gecko Multi-Protocol Wireless SoC Family Data Sheet
System Overview
3.13 Configuration Summary
The features of the EFR32MG13 are a subset of the feature set described in the device reference manual. The table below describes
device specific implementation of the features. Remaining peripherals support full configuration.
Table 3.2. Configuration Summary
Peripheral
Configuration
IrDA
Pin Connections
USART0
US0_TX, US0_RX, US0_CLK, US0_CS
SmartCard
I2S
USART1
USART2
US1_TX, US1_RX, US1_CLK, US1_CS
US2_TX, US2_RX, US2_CLK, US2_CS
SmartCard
IrDA
SmartCard
with DTI
-
TIMER0
TIMER1
WTIMER0
TIM0_CC[2:0], TIM0_CDTI[2:0]
TIM1_CC[3:0]
with DTI
WTIM0_CC[2:0], WTIM0_CDTI[2:0]
silabs.com | Building a more connected world.
Rev. 1.4 | 20
