EFR32MG13 Mighty Gecko Multi-Protocol Wireless SoC Family Data Sheet
Pin Definitions
GPIO Name
Pin Alternate Functionality / Description
Analog
Timers
Communication
Radio
Other
TIM0_CC0 #18
TIM0_CC1 #17
US0_TX #18
US0_RX #17
US0_CLK #16
US0_CS #15
US0_CTS #14
US0_RTS #13
US1_TX #18
US1_RX #17
US1_CLK #16
US1_CS #15
US1_CTS #14
US1_RTS #13
LEU0_TX #18
LEU0_RX #17
I2C0_SDA #18
I2C0_SCL #17
TIM0_CC2 #16
TIM0_CDTI0 #15
TIM0_CDTI1 #14
TIM0_CDTI2 #13
TIM1_CC0 #18
FRC_DCLK #18
FRC_DOUT #17
CMU_CLK1 #4
PRS_CH3 #9
PRS_CH4 #1
PRS_CH5 #0
PRS_CH6 #12
ACMP0_O #18
ACMP1_O #18
LES_CH2
TIM1_CC1 #17
FRC_DFRAME #16
MODEM_DCLK #18
MODEM_DIN #17
MODEM_DOUT #16
MODEM_ANT0 #15
MODEM_ANT1 #14
BUSDY
BUSCX
TIM1_CC2 #16
PD10
TIM1_CC3 #15
WTIM0_CC2 #30
WTIM0_CDTI0 #26
WTIM0_CDTI1 #24
WTIM0_CDTI2 #22
LETIM0_OUT0 #18
LETIM0_OUT1 #17
PCNT0_S0IN #18
PCNT0_S1IN #17
