V2 Valve
Value squared switching solenoid valve
PERFORMANCE CHARACTERISTICS
Orifice sizes/
Equivalent CV
Part no.
V210...
V213...
V214...
V217...
V220...
Pressure
0...100 psig
0...50 psig
0...30 psig
0...15 psig
0...6 psig
Vacuum
Leak rate2
Response
1
<30 msec cycling
(2 Watt)
0.030" (0.762 mm)/
0.017 CV
0...27 "Hg
(0...13 psi)
<30 msec cycling
(2 Watt)
≤0.2 sccm
0.050" (1.270 mm)/
0.035 CV
FLOW CURVES (typical air flow)3
Notes:
1
The CV value is the volume flow in US gallons/min under specific flow conditions and describes the relative flow capacity of a
valve. If several valves with the same nominal diameter are compared, the valve with the highest CV value has the best flow
dynamics design. The equivalent european measure is the kV value expressed in m3/h (kV = 0.86 CV).
sccm denotes Standard Cubic Centimeters per Minute. It is a unit for the flow rate at standard conditions of temperature and
pressure. 1000 sccm = 1 slpm.
2
3
slpm denotes Standard Liters per Minute. It is a unit for the flow rate at standard conditions of temperature and pressure.
1 slpm = 1000 sccm.
