S3C4510B
INSTRUCTION SET
DATA PROCESSING
The data processing instruction is only executed if the condition is true. The conditions are defined in Table 3-2.
The instruction encoding is shown in Figure 3-4.
31
28 27 26 25 24
21 20 19
16 15
12 11
0
00 Opcode
L
S
Rn
Rd
Cond
Operand2
[15:12] Destination Register
0 = Branch 1 = Branch with Link
[19:16] 1st operand Register
0 = Branch
1 = Branch with Link
[20] Set condition Codes
0 = Do not after condition codes
1 = Set condition codes
[24:21] Operation Code
0000 = AND-Rd: = Op1 AND Op2
0001 = EOR-Rd: = Op1 EOR Op2
0010 = SUB-Rd: = Op1-Op2
0011 = RSB-Rd: = Op2-Op1
0100 = ADD-Rd: = Op1+Op2
0101 = ADC-Rd: = Op1+Op2+C
0110 = SBC-Rd: = OP1-Op2+C-1
0111 = RSC-Rd: = Op2-Op1+C-1
1000 = TST-set condition codes on Op1 AND Op2
1001 = TEO-set condition codes on OP1 EOR Op2
1010 = CMP-set condition codes on Op1-Op2
1011 = SMN-set condition codes on Op1+Op2
1100 = ORR-Rd: = Op1 OR Op2
1101 = MOV-Rd: =OP2
1110 = BIC-Rd: = Op1 AND NOT Op2
1111 = MVN-Rd: = NOT Op2
[25] Immediate Operand
0 = Operand 2 is a register
1 = Operand 2 is an immediate Value
[11:0] Operand 2 Type Selection
11
3 4
0
Shift
Rm
[3:0] 2nd Operand Register
11 8 7
Rotate
[11:4] Shift applied to Rm
0
Imm
[7:0] Unsigned 8 bit immediate value
[11:8] Shift applied to Imm
[31:28] Condition Field
Figure 3-4. Data Processing Instructions
3-9
