Preliminary
AM/FM TUNER + MPX + PLL
S1A0903X01
CHARACTERISTICS
ABSOLUTE MAXUMUM RATING
Parameter
Supply Voltage
Symbol
VS
Rating
10
Unit
V
Remarks
Operating Temperature
Storage Temperature
Power Dissipation
Top
-20 - + 75
-55 - + 150
1800
°C
Tstg
°C
Pdmax
mW
TEMPERATURE CHARACTERICS
Parameter
Symbol
DIcc1
Condition
Rating
20
Unit
uA/°C
uA/°C
Remarks
Quiescent circuit current 1 (FM)
Quiescent circuit current 2 (AM)
-20 - + 70°C
-20 - + 70°C
DIcc2
20
ELECTRO_STATIC DISCHARGE CHARACTERISTICS
Parameter
Human Body Model
Machine Model
CDM
Condition
C = 100pF, R = 1.5kW
C = 200, R = 0kW
-
Pin No.
All pins
All pins
All pins
Rating
± 2000
± 300
Unit
V
Remarks
V
± 800
V
5
SAMSUNG [ SAMSUNG ]
